SPECIFICATIONS |
|
|
TEMPERATURE RANGE |
50°-600°C/125-1100°F |
TIP TO GROUND RESISTANCE |
<2  (DC) |
|
| |
STABLE TEMP. CONTROL |
±2°C/±36°F |
TIP TO GROUND POTENTIAL |
<2mV(True RMS) |
|
| |
INPUT VOLTAGE/FREQUENCY |
220v/110v |
AUTO IDLE |
Yes |
|
| |
POWER CONSUMPTION |
60W-90W |
TEMPERATURE LOCK MODE |
Password Protected |
|
| |
HEAT UP TIME |
20-25 Seconds |
ESD HOUSING |
Aluminum |
|
| |
MAX TIP TEMP. DROP |
20°C/68°F |
DIMENSIONS (LxWxH) |
160x130x100mm/6.3x5.1x3.9in |
|
| |
HEATING SOURCE |
High Frequency Current |
WEIGHT |
2kg/4.4lbs. |
|
|
|
|
| |
| |
| |
| |
|
